Kimyasal Monoblok Pompa BN
Chemical motor block pump BN to DIN/EN 22858
BN motor pump units are normal-priming, single-stage, horizontal plastic centrifugal pumps. Their dimensions and flow rates largely correspond to DIN/EN 22858, which simplifies replacement of standard pumps in existing installations.
The series was developed for the requirements of the chemical industry and is especially suited to pumping pure or solids-containing, acid or alkaline, low-viscosity liquids. As the wetted materials are physiologically harmless, the pumps can also be used in the food industry. The extended shaft of the drive motor carries the impeller directly, and the pump head is flanged to the motor with an intermediate piece.
Key features
- Dimensions and flow rates to DIN/EN 22858
- Normal-priming, single-stage, horizontal design
- Block design — no coupling or baseplate required
- For acid, alkaline and solids-containing liquids
- High-quality, chemically resistant wetted-end materials
- Physiologically harmless materials — suitable for the food industry
Technical data
Technical specifications
| Type | Block design, normal-priming, single-stage |
|---|---|
| Standard | Dimensions and flow rates to DIN/EN 22858 |
| Media | Acid, alkaline, solids-containing low-viscosity liquids |
| Applications | Chemical and food industry |
